Shanghai ELE Mechanical and Electrical Equipment Co., Ltd. is one of the most reliable manufacturers and suppliers of ebf series hydraulic lifting high speed disperser in China. Welcome to buy cost-efficient ebf series hydraulic lifting high speed disperser for sale here from our factory. Quality products and reasonable price are available.
The High Speed Disperser applies to all kind of liquid to pre-mix,disperse,color matching,etc
High-Efficiency production,hydraulic lifting,frame can turn around flexible.when mixing and dispersing,there is little air suction.it can dissolve the material quickly and particle become finer
Working principle
 High Speed Disperser |
|
Hydraulic Lifting High Speed DisperserSpecification
Model/ Paramter | Main Power (KW) | Rotation speed (rpm) | Diameter of disc (mm) | Stroke (mm＜) | Pump power (KW＜ ) | Weight (Kg) | Length (mm＜) | Height (mm＜) | Centre Distance(mm) |
EBF-4 | 4 | 1400 | 100-200 | 700 | 0.75 | 700 | 1400 | 1420 | 580 |
EBF-7.5 | 7.5 | 1400 | 200-300 | 900 | 0.75 | 1000 | 1650 | 1850 | 765 |
EBF-11 | 11 | 1400 | 200-300 | 900 | 0.75 | 1000 | 1650 | 1850 | 765 |
EBF-15 | 15 | 1400 | 200-300 | 900 | 0.75 | 1000 | 1800 | 1850 | 915 |
EBF-18.5 | 18.5 | 1250 | 300-400 | 1200 | 0.75 | 1500 | 1800 | 2120 | 1100 |
EBF-22 | 22 | 1250 | 300-400 | 1200 | 0.75 | 1500 | 2360 | 2120 | 1250 |
EBF-37 | 37 | 1250 | 300-400 | 1200 | 1.1 | 1800 | 2520 | 2120 | 1400 |
EBF-45 | 45 | 1250 | 400-500 | 1500 | 1.1 | 1800 | 2830 | 2750 | 1400 |
EBF-55 | 55 | 1250 | 400-500 | 1500 | 1.1 | 2000 | 2830 | 2750 | 1500 |
Advantage
1.The machine with this special built-in structure will decrease some unnecessary problems;
Your production will not be influenced by leaking oil
2.The structure of inner oil hydraulic cylinder only need little oil and no leak,stable rise and fall
Application
Coating: Water-based coating, Solvent-based coating,Decorative Coating,Latex paint;
Paint: Car Paint, Finish paint, Wood paint, Industrial paint;
Pigment: Dye, Color painted pigment, Pen liquid，Watercolor;
Electronic Materials: Battery diaphragm alumina, Lithium iron phosphate, Ceramic slurry, Flame retardant;
Daily Chemical Industry: Cosmetics, Liquid soap, Shower gel, Liquid detergent etc;
Nano Materials: metal oxide, Magnetic Materials, Paper industry, Optoelectronic industry.
Professional technical supports & Processing Machines
We have lathes, grinder, drilling machine, boring machine, polishing machine, milling machine…etc.
 Office |  Fine process center |  Fine process center |
 Polishing center |  Welding |  Gringding |
Maintenance & Services
1.We provide you opeatian manual by chinese or English;
2.With three years of spare parts inventory to ensure normal use and make you to be in trouble free;
3.After the warranty period, we provide maintenance and maintenance service, only charge the cost;
