Bead Mill

ELE Bead Mill Machine cooperates with Switzerland technology, with advanced structure, high efficiency, nanometer, and micron final fineness. It adopts specially wear-resisting materials, prolonging service life, and well adapted to different viscosity of materials.

It is widely used in the industrial production of paint, color paste, printing ink, papermaking, adhesive, drugs, chemical industry, etc.

ELE Bead Mill Machine Series

ELE Bead mill includes three types: Pin type bead mill, Turbo type bead mill and Disc type bead mill, for different usages and different viscosity, different particle size requirements.

Disc Type Horizontal Bead Mill machine

Micro grinding bead mill and Economic bead mill, With new technology tubular discharge sieve, Large flow capacity and suitable for middle and low viscosity products.

Pin Type Horizontal Bead Mill Machine

Nano grinding bead mill and high energy sand mill, higher linear velocity and narrow particle size distributor, Suitable for different viscosity products, include high viscosity.

Turbo Type Horizontal Bead Mill

Nano grinding bead mill and higher energy sand mill, special accelerator to reach maximum speed, Narrow particle size distributor, Low maintenance cost.

Laboratory Bead Mill

Laboratory scale bead mill, nano grinding, high energy and high linear velocity, Narrow particle size distributor, suitable for lab research and small batch production, Pin type and turbo type for option.

Pin type and Turbo type are nano grinding mill, with the special short and fat grinding chamber, energy is concentrated, with higher tip speed and higher impact force and friction force. Disc type is cost-effective sand mill, suitable for that product which don’t required too much on particle size.

Data Sheet

ELE: Your Leading Bead Mill Machine Manufacturers in China

● Over 20 Years Manufacturing Experience

Shanghai ELE established since 1996, built China mainland factory at 2006, with R & D, Manufacturing, Global sales & Marketing together.

As a leading bead mill manufacturer with 20 years ,This Bead Mill manufactured by ELE team is your reliable Wet Grinding partner, which can grind products into small particle size, like micron size, nanometer size, it will solve all the ticklish problems in processing, like material fineness, temperature, output, pure color and metal contaminations.

ELE bead mill provide three kinds of material for options, suitable for different application area:

1).Harden Alloy Steel rotor and inner grinding chamber,

2).Ceramic Material: Zirconia Rotor and Silicon carbide inner grinding chamber,No metal contamination, better in heat conductivity, suitable for electrical material, medicine , food that requires free-metal.

3).PU material: polyurethane Rotors and inner grinding chamber No metal contamination

ELE Bead mill machine Widely used in:Paint、Ink、Pigment、Pesticide、Biological、Medicine、Golves 、Electronic Materials、Nano Materials,and many other applications

The capacity of the bead mill ranges from 5L to 100L and can grind to nanometer 50nm~500nm ,micron-size 1 micron~ 10 microns...

● Reputation certification

As a leading bead mill manufacturer with 20 years of experience, all bead mills manufactured by ELE® undergo 100% testing before delivery to ensure that the products meet the delivery conditions.

ELE Bead mill machine have CE, SGS, TUV certificate.

ELE is the only manufacturer who has its own mechanical seal patent in Shanghai. Patent No.: 201610459850.7

● Quality Control

With around 25 years rich experienced engineers in this area, ELE strictly control the every single process from raw material to processing, to assembling to final products testing. Strictly control the accuracy during processing,

For equipment, superior performance sometimes does not mean good quality. Quality can be understood as mechanical stability which means it will not be damaged or malfunction frequently. Therefore, the definition of an excellent equipment should has excellent mechanical stability on the basis of superior performance.However,how to ensure the quality of the equipment? We think It needs to start from two aspects:

1. High requirements for accuracy;

2. Strict quality control management system

First of all, accuracy is extremely important to the equipment. For example, if the accuracy of the sand mill is not good, the main shaft will happen runout greatly, which will damage the mechanical seal in a short time and seriously affect the service life of the mechanical seal.

However, accuracy is actually a display of the comprehensive technical level and manufacturing capabilities of the machinery manufacturer due to it involves many aspects of manufacturing. For example, excellent design(structure), complete and high-quality process equipment (machine tools), reasonable and excellent processing technology, skilled technical workers, strict inspection system,and so on. The figure below is a simple diagram.

For quality control, ELE has strict requirements at every step. We have a professional inspection department which is responsible for each step of the inspection, and we also have a strict inspection system which involves in inspection of raw materials, single processed parts, assembly parts, dynamic and static inspection of machine.,and so on.

In summary, Excellent design&accuracy&quality control management system are a solid guarantee for the quality of ELE equipment.

Bead Mill Machine: The Ultimate FAQ Guide

What is Bead Mill Machine?

Bead mill machine is also called pearl mill or sand mill. These names strongly indicate that this mill is working on beads or pearls…It is mainly used for wet grinding of all kinds of  the chemical liquids, such as paint, coating, ink, pigment, pesticide…any chemical liquids which pursue smaller particle size, like micro or even nano-meter…According to the performance, Agitator Bead mill can be roughly divided into  horizontal bead mill(simply we call it bead mill), basket mill,  vertical ball mill . The machine is mainly composed by the body shell, the grinding cylinder, the grinding disc, the grinding medium, the motor and the feeding pump. The feeding speed is controlled by the feeding pump. The grinding media of the device are generally classified into zirconia beads, glass beads, zirconium silicate beads, steel balls. Technically, smaller beads can achieve smaller particle size..

Bead Mill is a wet grinding mill, which can grind products into small particle size, like micron size, nanometer size, it will solve all the ticklish problems in processing, like material fineness, temperature, output, pure color and metal contaminations.

Bead Mill is the high efficiency, high energy wet grinding mill, with the multiple cooling system, automatically stop control system, with continuous production system.

The bead mill is the most widely used, most advanced and most efficient grinding equipment so far. The grinding chamber is the narrowest, the gap between the grinding disc is the smallest, the grinding energy is the most dense, and with the high-performance cooling system and automatic control system, bead mill can realize continuous working, which greatly improves the production efficiency.

Horizontal bead mill is developed based on ball mill. According to different structure(mostly the different grinding disc)And it can be classified as disc type horizontal bead mill, pin type horizontal bead mill, turbo type horizontal Agitator Bead mill…Different type has different performance and you can choose the right machine according to your product and your working capacity.

What Are the Advantages of Bead Mill Machine?

The advantages of bead mill very obviously compare with other grinding mills ( basket mill, three roller mill )

From bead mill and basket mill and three roller mill working principle

You can see bead mill's most obvious advantage is suitable slurry mass continuous production and high production efficiency.

Bead mill machine can grind to nano-size 50nm,100nm,200nm,500nm...

Bead mill machine also can grinding to popular micron size 1 micron, 2 microns 5 microns,10 microns...

High performance and high energy

Grinding media is evenly distributed inside the grinding chamber, the final particle size is narrowly distributed.

ELE-NET0.1 discharging sieve is designed for superfine material, to ensure of large flow rate, and microbeads can be used at the same time;

Selection of special material (zirconia/silicon carbide/hard alloy steel etc.) enhance the wearability of all processing contact parts, It adopts an internal thread type cooling way, effectively improves heat dissipation in the grinding chamber.

Unique double cartridge mechanical seal, to ensure long operation of the shaft seal, maximum 8 -10 kg pressure

Special Feeding System

Feeding pump with buffer tank to make sure feeding smoothly, buffer tank with pressure meter, If the grinding chamber is blocked, we can release the pressure from the buffer tank

Discharging System: New technology of Discharge method

Large Area centrifugal separator, the centrifugal wheel push away the grinding beads from the discharge sieve, make sure discharge smoothly, no blocking of beads

Special Mechanical Seal & Bearing Housing

● Special double cartridge mechanical seal, ensure long operation of the shaft seal, maximum 8 -10 kg pressure;

● Special Bearing Housing, match mechanical seal well, one whole part, ensure the accuracy to below 0.03mm. Make sure stable working & extend the long life.

Cooling system

● High-efficiency large area spiral ribbon type jacket water circulation chamber wall cooling

● Feeding pipe with the jacket for cooling

● End cover corrugated cooling

● Cooling Tank for Mechanical Seal

Are There Limitations of Bead Mill Machine?

we have lab bead mill and large production bead mill , Most materials can use our bead mill grinding, Except for materials with high viscosity or poor fluidity can not use Agitator Bead mill, But from our experience, high viscosity materials not require high fineness.

What is Bead Mill Machine Used For?

Bead mill machine use for slurry grinding ,widely use these industry

● Paint: Decorative paint ,Car paint, Wood paint, Floor paint metal paint etc;

● Ink: Gravure Printing ink, Flexographic ink, Offset printing ink, Silk screen ink, UV light solid ink, Digital inkjet ink etc;

● Pigment: Pigment ,Dye, Color painted pigment, Pen liquid，Watercolor;

● Pesticide: Pesticide suspension, SC,EC, EW, ME;

● Biological Medicine: Algae cell fragmentation, Micro-biological functional materials;

● Golves : Labor,latex ,nitrile gloves

● Electronic Materials: Battery diaphragm alumina, Lithium iron phosphate, Ceramic slurry, Flame retardant;

● Nano Materials: metal oxide, Magnetic Materials, Paper industry, Optoelectronic industry.

Which Are the Parts of Bead Mill Machine?

Bead mill machine mainly consists of feeding pump, grinding chamber, grinding beads, motor, machine body, cooling system, protection system,control system ...etc.

Let's take ESW-1.0 bead mill as an example. Details are showed as follows:

Which Other Technologies Can Replace Bead Mill Machine?

Basket mill can be a replacable mill machine of bead mill. It can achieve utlra-fine grinding effect too. Comparatively speaking,  the two types machine have its own advantages.

For bead mill, motor power is larger,  beads filling ratio is higher, grinding time is shorter and target particle size distribution is narrower. And it can be used to continuous production in that the bead mill is highly automated. Not only because protective devices can be installed on the bead mill and it can automatically shutdown if machine pressure beyond set value, so that one person can operate multiple machines,  but also because the machine cleaning and grinding process are the same , thus don't require workman to do cleaning else. But the price is higher.

For basket mill, it can do grinding and dispersing together, convenient to operate and easy to clean so it particularlly suitable for paint and ink production with many colors. But it requires workman to transfer materials and clean inner  basket  chamber after grinding every time. And also it can't be used in continous production. But price is lower.

How Does Bead Mill Machine Work?

Motor of bead mill machine drive in high speed, bring the rotors (Pin/Turbo/Disc) in high speed rotation, the beads between the rotors are moved fast and collide each other, bring shearing force, impact force and hitting force to the particles, break the particle to be smaller size. With the help large area centrifugal separator sieve, the grinding media keep stay inside the grinding chamber, the particles go through the sieve gap (usually 0.1mm, 0.3mm, 0.5mm, we also can make 0.05mm) for discharge.

A horizontal bead mill is wet grinding machine for continuous production. The working way is:

Working Principle

Feeding pump: like diaphragm pump or gear pump, to transferring the material into the grinding chamber which is filled with grinding media (normally it is Zirconia Beads, glass beads or steel beads. We recommend you 95% zirconia content Zirconia beads).

Grinding: These beads move along with high-speed Grinding disc. The grinding beads hit against the material which needs to be grinded with high power.

Discharge: After thousands of times hitting, the material will get smaller particle size, and then it will be separated with the beads by a special sieve which installed in the middle of the grinding chamber cover.

Compared to three-roller mill, bead mill doesn’t need high working skill, easy to operate, and bead mill can work continuously on production line, by this way, using bead mill, you will get high quality product, and lower cost.

On the market, there are several types bead mill such as: disc type bead mill, pin type bead mill, turbo type bead mill, and each type have different size, to satisfy different customer’s need: different product, different viscosity, different working capacity….

In all, bead mill is now widely used in Industry such as: paint, ink, medicine, food, cosmetics, pesticide…

How Many Types of Bead Mill Machine Are There?

In terms of machine rotor structure, we have three types: disc type, rod pin and turbine. In terms of rotor and cavity materials, we have alloy steel, ceramics, and polyurethane.

How Do You Troubleshoot Bead Mill Machine?

Generally, our equipment will be shut down when a failure occurs. Do not rush to restart the machine at this time. Turn on the electric control cabinet first and the fault indicator will light up. Through the fault light, we will find out the corresponding fault location and cause.

Fault indicator

Fault indicator

Faults and Troubleshooting Method:

A)Feeding pump can not transfer materials or showing pressure>2kg on the pressure meter

I.  Check feeding pump

II. Check whether chamber discharging end blocking, open the outlet port nozzle, clean the discharging sieve.

B) Main motor doesn’t work

III. Check power supply

IV. Security instrument is in protection state, floating ball of liquid level falls to the bottom of the central pole or pressure in mechanical seal cooling tank is too low, ﹤0.25Mpa.

V. Check thermal relay

VI. Check whether cooling liquid transfer pump is working normal

C) Rotor don’t rotate ( while main motor is working)

VII. V-belt is too tight

VIII. Rotor is stuck by media or materials

After troubleshooting, press the emergency stop button. Restart the machine

What Are the Factors That Affect the Service Life of the Bead Mill Machine?

Failure to operate the machine in accordance with our training guidelines.

1. The feed particles are too large or the viscosity is too high to cause the machine block, and the machine is forcibly restarted when the fault is not eliminated. It is very likely that the mechanical seal will be damaged after several times, resulting in liquid leakage.

2. When the current and voltage are unstable, it will cause damage to the motor and abnormal shutdown.

3. The cleaning of the material is not complete, and the material remains in the cavity, which causes the filter screen to be blocked.

4. The mismatch of the selected zirconia beads and the filter screen, and the feeding speed is too fast, will cause the machine to block and cause the shutdown phenomenon.

The above behaviors will affect the service life of the machine.

Which Factors Control Particle Sizes in Bead Mill Machine?

There are many factors that may influenced the final particle size, such as：

1. Grinding type, there are three types bead mills in term of grinding types, Disc type, Pin Type, Turbo type, each type due the grinding efficiency and energy consuming different, the final particle sizes will be different too.

2. Zirconia beads size,  when bead mill working , shaft bring engergy to zirconia beads which cause crushing power on the particle size, the gap space among beads and beads influence the smallest particle size it can reach.

3.Beads loading ratio, in a reasonable scale, the higher beads loading ratio, the higher grinding efficiency, more beads means more crushing power and possibility that hits the particle size.

4.Speed, the higher rotating speed brings higher power and energy, in reasonable scale, the speed is higher means efficiency is higher too.

5.Feeding speed, feeding speed lower means that material has longer grinding time in the grinding chamber, this influence the final particle size too.

6.Temperature, pressure, etc, according to different material characteristics, sometimes temperature and pressure will influence the final particle size too.

What Are Bead Mill Machine Specifications?

When we say the specifications of a bead mill, we generally starts from the following aspects:

1.the grinding type, such disc type, pin type and turbo type.

2.the grinding part material, metallic and ceramic.

3.the motor power.

4.the grinding chamber volume

5.the sieve size

6.the zirconia beads size

7.the other assisting devices

Which Factors Determine Quality Bead Mill Machine Output?

1. the machine handling capacity, flowrate. Bigger motor power always has bigger grinding chamber, meanwhile bigger flowrate.

2. the final particle size requirements, according to different particle size requirements, the grinding time, speed and rounds could be different.

3.the feeding speed, the higher feeding speed lead a higher outputing speed.

● What Influences the Capacity of  Bead Mill Machine?

● Bead Mill Machine Should Conform to Which Quality Standards?

● Which Material is Used to Make Bead Mill Machine Contact Parts?

The contact part of bead mill mainly consists of two parts: Rotor and Lining. For details,pls check the picture below:

What Are the Properties of Materials You Can Process Using Bead Mill Machine?

Horizontal sand mill is a wet fine grinding equipment. Its main function is to break the phenomenon of secondary agglomeration of particles. At the same time, it has a certain crushing ability according to different physical properties. Therefore, the products produced by sand mill must have at least the following two characteristics:

1. The working manner of sand mill is wet grinding, so the material is required to have fluidity and be in the state of slurry, liquid, solid-liquid mixture, etc. The products produced by the sand mill are finally in the state of fluid slurry, suspension agent, etc., not powder state.

2. Sand mill is aimed at fine grinding, so it has requirement for the feeding particle size (preferably less than 100 microns). The material needs to be fully pre-dispersed before entering the sand mill.

How Do You Charge and Discharge Material from Bead Mill Machine?

The horizontal sand mill has two discharging methods, one is the outdated dynamic and static ring discharging mode（gap separator), and the other is the current popular large-flow centrifugal tubular separator discharging mode. The comparison of the two methods is shown in the figure below:

Comparison Between Dry and Wet Bead Mills?

Talking about grinding bead mill, there are dry grinding and wet grinding two methods, As for the nano material powder manufacturer, of course, they wish to use dry grinding to get nano particle, but for dry grinding, the temperature of powder will be increased quickly by the high energy impacted, besides when the powder become nano particle how to prevent the explosion proof, it is hard to solve. SO here comes the wet grinding, It is the cost-effective, Avoid the high cost and solve the problem of dry grinding hard to reach nano particle, usually for dry grinding, it only can reach 8microns, if you want finer, then better to choose wet grinder.

For dry grinder methods, usually we could use below machines:

1) Jet Mill

2) Ball Mill

3) High pressure Agitator mill;

For Wet grinder methods usually we could use below machines:

1) Pin type bead mill

2) Turbo type bead mill

3) Disc type bead mill

The difference is as below:

1)     Dry grinder: Advantages: short production time, low cost, Disadvantages: Power is easy to get aggregation, Hard to reach nanometer particle size, Easy to increase temperature when grinding

2)     Wet grinding mill: Advantages: Could reach nanometer particle size, high efficiency;  Disadvantages: Long production time, after treatment is very complicated and high cost

How about ELE Agitator Bead Mill service?

We ELE provide one year warranty time and life time maintenance service. Includes below services:

1)     Guide to install the machines and commissioning

2)     Train the customer about the maintenance notices

3)     Provide technical support

4)     Guarantee the spare parts supply

5)     Provide the regular maintenance service

6)     Provide the Regular return visit by telephone or at home

7)     Sales and engineers are 24hours online to solve your problem

How to choose a suitable bead mill?

What kind of products you will grind? Water-based or solvent-based

What is the viscosity? How many cps ？

What is the final particle size you want to reach? How many microns?

What is the initial particle size? How many microns?

What is your working capacity? How many liters per batch or per hour?

Please contact our sales and inform him/her of product information

How To Choose The Suitable Bead Mill According To The Capacity Requirements?

Commonly used production bead mills are 5L, 10L, 15L, 30L, 50L, 100L, etc.

This refers to the volume of the grinding chamber of the bead mill, However, many user no idea about what is the relationship between this grinding volume and the production capacity of Pearl mill ...Read more

How To Choose The Bead Mill For Different Fineness Requirements?

At present, Our company main bead mill types include disc bead mill, pin bead mill, and turbo bead mill.

Normally , the disc bead mill grinding fineness worse than pin type and turbo bead mill. The disc bead mill more used when the fineness requirements are not high, example 10 microns fineness or the micron grade fineness is required..Read more

Why ELE bead mill equipped zirconia, silicon carbide, polyurethane, high wear-resistant alloy steel for options?

When customer choosing the Wet grinding mill, Customer will feel that there are too many material configurations of the bead mill. Them don’t know choose which one ... Read more

How To Adjust The Grinding Fineness Of ELE Bead Mill?

If the grinding fineness of the bead mill can be adjusted?  Yes ,it can be adjusted.

But it can only be adjusted within a certain range. Why will say that?

Because it depends on the physical properties of the material. Read more

What Should Be Paid Attention To When Choosing A Bead Mill For Solvent-based Paints And Inks? Explosion-proof And Mechanical Seal Especially Important!

When it comes to solvent-based paints and inks, explosion-proof are often considered when considering equipment selection. When asking ELE professional engineers, they will actively ask whether the material is solvent based or water-based...Read more

How Long Does It Take To Replace The Filter Screen Of The ELE Bead Mill?

The filter screen of the bead mill is a very important part. Its function is to keep the grinding beads in the grinding cavity, and the material discharge smooth. As material fineness requirements become finer, the grinding beads used are getting smaller and smaller. This requires higher and higher precision of filter screen area...Read more

What Is The Amount Of Zirconium Beads Added To The Bead Mill?

Whether the amount of zirconium beads added in the bead mill is appropriate will directly affect the working efficiency and fineness of the Wet grinding mill during grinding. Too little will reduce the efficiency and fineness, and too much will cause problems such as excessive heat generation...Read more

Is It Easy To Clean The Bead Mill After Grinding The Color Paste

The cleaning problem of the bead mill after grinding the color paste is the most troublesome thing for all people who have used grinding mill. The workload is too large, and it takes time and solvent, which is very troublesome. If compare which bead mill is the most convenient for cleaning. The most powerful answer to this question is bead mill operators of color paste...Read more

Is there much residual material in the grinding chamber of the wet grinding mill?

The residual amount of materials has always been a general concern of users, and the amount of residual amount is also an important indicator to measure the rationality and cost-effectiveness of a piece of equipment...Read more

What are the wearing parts of the horizontal bead mill?

After normal use, the horizontal bead mill will produce damaged parts like all machinery, These normal damaged parts are called wear parts.  So, what are the wearing parts of the Pearl mill ...Read more

What is the difference between nano bead mill and ordinary bead mill?

Nano bead mill are not actually developed in recent years. Nano bead mill appeared internationally as early as 2000. As an application of high-end technology, they play an important role in many fine chemicals and new materials,However...Read more

Why some pin type bead mill not as fine as the ELE pin type bead mill?

The emergence of the pin bead mill has completely changed the original traditional horizontal bead mill where the fineness can only be ground to the micron level...Read more

ELE is with Bead Mill R&D, manufacturer, global sales & marketing together, the engineers are more than 20years in this area, with skillful technologies & rich experiences. With CE certificate and approved patent certificate. Exported to many countries, like the USA, Canada, Spain, Poland, Italy, France, Saudi Arabia, UAE, India, Pakistan, Bangladesh, Thailand, Malaysia, Singapore….etc.

Bead Mill Vs Ball Mill

At present, the Bead mill and ball mill are two different types of equipment, but in fact there is a certain relationship between them, because the bead mill is developed from the basis of the ball mill, Both are using the grinding medium between the collision, extrusion, friction and other principles of crushing materials. But there are essential differences and applications between Bead mill and Ball mill...Read more

Hot Tags: bead mill, suppliers, manufacturers, cost, price, for sale
